Lunatone Wireless 0-10V PWM interface with integrated 8A relay. The set consists of a transceiver and a receiver and is used to wirelessly control lights with 0-10V / 1-10V / PWM operating devices. The transmitter is connected to and powered by the DALI bus (3.8mA). The receiver has a 0-10V PWM output and a relay function and is powered by mains voltage. The wDALI RM8 0-10V enables the wireless integration of electrical devices such as floor lamps and outdoor lighting into a DALI system. Under optimal conditions the reception range is 300m, in buildings usually 10-20m.
Specifications- wDALI RM8
Technical data
| Ambient temperature | 0 ° C to + 45 ° C |
| Protection class | IP20 |
| Connection Wires cross section | Max. 1.5mm² |
| Assembly | Can installation |
Electrical data
| Supply | 210-250V AC / 50-60Hz |
| Output | 0-100% PWM (16bit, 488Hz), current sink 1mA |
| Nominal load | 1000VA |
| Max. Switching current | 8A |
| Max. Inrush current peaks | 80A |
| Relay contact | 1 on / off, max. 30000 switching cycles at nominal load resistive, max. Switching frequency 1Hz |
| Frequency band | 2.4Ghz |
Specifications- wDALI Transceiver
Technical data
| Ambient temperature | -10 ° C to + 50 ° C |
| Protection class | IP20 |
| Connection wires cross section | Max. 1.5mm² |
| Assembly | Can installation |
Electrical data
| Supply | From DALI Bus |
| typ. current consumption | 3.8mA |
| Output | DALI |
| Function | programmable, Power On refers to the return of the bus supply |
Function
| Device Type | wDALI Control gear |
Dimensions
| Length, Width, Height | 59mm,33mm,15mm |
| Colour | Grey |
